High-Precision Dual-Spindle Mounting Bracket Solutions
A well-designed dual-spindle mounting bracket plays a critical role in maintaining structural stability, positional accuracy, and consistent parallel alignment between two mounted units. When the spacing or angle deviates even slightly, it can affect overall assembly precision, operating smoothness, and long-term component reliability.
Our solution combines custom mold manufacturing with high-tolerance CNC machining to deliver brackets that meet demanding structural and dimensional requirements.
Tooling for Complex Angles:
Our engineering team develops precision molds to create complex angled shapes, reinforced walls, and integrated mounting features. This allows the bracket to fit compact assemblies while providing stable support for motors, sensors, shafts, or other paired components.
Accurate Twin-Bore Machining:
For critical alignment areas, molding alone is not enough. We apply precision CNC boring and finishing to the twin holes and key mounting surfaces, ensuring excellent concentricity, parallelism, and fit accuracy.
Reliable Structural Performance:
With the combination of optimized mold design and secondary machining, our dual-spindle mounting bracket offers high rigidity, dependable positioning, and consistent performance in precision mechanical assemblies.
Dual-Spindle Mounting Bracket Mold Parameter
| Item | Details |
|---|---|
| Mold Base Material | LKM C50, P20, cast iron, and more |
| Mold Standards | HASCO, DME, MISUMI |
| Surface Hardness | Above HRC45 |
| Insert Material | Dievar, H13, and more |
| Cavities | 4 cavities |
| MOQ | 1 set |
| Mold Lead Time | T1 sample, about 3–10 weeks, according to mold requirement |
| Production Lead Time | 2–5 weeks, according to order quantity |
| Mold Payment Term | 50% T/T deposit with PO, balance 50% T/T after sample approval |
| Products Payment Term | 30% T/T deposit with PO, balance 70% T/T before shipment |
| Port of Loading | Ningbo or Shanghai port |
