Aluminum Component Die Casting Mold
Moldie designs and builds die casting molds for aluminum components across general OEM part families. We deliver production-ready mold tooling matched to component drawings, with DFM and tryout scoped to the specific component geometry supplied.
What this mold is for
This page covers mold tooling for general aluminum die cast components. Application and part function are confirmed per project from drawings. Casting alloy choice (aluminum alloys as specified for the part) is separate from mold steel selection for the die.
Tooling scope
- DFM review for aluminum component geometry and machining stock
- Mold design: parting, gating, runners, overflow, venting, and ejection
- CNC machining of cavities/cores, fitting, and assembly
- Tryout support and dimensional feedback for aluminum component samples
Materials note
Part alloy (aluminum alloys such as ADC12, A380, or AlSi grades as specified for the part) and mold steel (tool steel with appropriate hardness for die casting dies) are specified separately. Do not treat part-alloy hardness or surface treatments as mold-steel heat treatment.
Ask for a quote with drawings, alloy, press tonnage, annual volume, and inspection requirements. Related: die casting molds and mold design & engineering.
