Aluminum Pressure Die Casting Mold
Moldie supplies custom high-pressure die casting molds for aluminum pressure die casting projects. We engineer the tooling that produces the casting: cavity and core design, runner and gate layout, cooling circuits, and ejection suited to the part geometry.
What this mold is for
- Production die casting tooling for aluminum pressure die casting applications
- Dimensional control to your 2D/3D drawings and tolerance stack-up
- Tool construction oriented to stable, repeatable casting cycles
Tooling scope
- DFM review before steel cutting
- Mold base and inserts in production tool steels (e.g. H13 / 1.2344 class inserts as specified)
- Process options for aluminum, zinc, or magnesium HPDC as applicable to the project
- Tryout and surface-support items as agreed in the project plan
Basic information
- Brand: Moldie
- Mold base: LKM / C50 + P20 for A/B plates, cast iron, or as specified
- Inserts (cavity & core): Dievar, H13, 8407, 1.2344, or customer-specified steel
- Standards: HASCO, DME, MISUMI, PUNCH, etc.
- Typical casting alloys (as applicable): ADC12, A380, Zamak grades, AZ91, and related alloys
- Part surface processes (on castings made with this mold): sand blasting, powder coat, painting, anodizing, plating, etc.
- Process: high pressure die casting
- Quality system: ISO 9001:2015
Share your 2D/3D drawings and annual volume for a DFM check and tooling quotation.
