Aluminum High Pressure Die Casting Mold
Moldie designs and builds high pressure die casting (HPDC) molds for aluminum programs. We deliver production-ready mold tooling matched to your drawings and HPDC process inputs, with gating and venting planned for high-pressure aluminum fill.
What this mold is for
This page covers aluminum high pressure die casting mold tooling. Typical discussions include HPDC machine interface expectations, runner/gate strategy, and tryout sample review. Casting alloy choice (aluminum alloys as specified for the part) is separate from mold steel selection for the die.
Tooling scope
- DFM review for aluminum HPDC flow, filling, and machining stock allowances
- Mold design: parting, gating, runners, overflow, venting, and ejection for HPDC molds
- CNC machining of cavities/cores, fitting, and assembly
- Tryout support and dimensional feedback for first HPDC aluminum samples
Materials note
Part alloy (aluminum alloys such as ADC12, A380, or AlSi grades as specified for the part) and mold steel (tool steel with appropriate hardness for die casting dies) are specified separately. Do not treat part-alloy hardness or surface treatments as mold-steel heat treatment.
Ask for a quote with drawings, alloy, press tonnage, annual volume, and inspection requirements. Related: die casting molds and mold design & engineering.
